Caterpillar Grader Moldboard Blade Hanger Bracket Welding and Line Boring Repair

Here’s some pics of a bracket, or blade hanger, on our CNC boring & milling machine. This piece attaches to the underside of the drawbar on a 16G Caterpillar grader. The blade, or moldboard, hangs from & slides side-to-side on the bottom of this bracket. The bores where the blade hanger pins up to the [...]

2025-05-23T05:24:09+00:00May 23rd, 2025|Machine Shop|

Caterpillar Mini Excavator Mitsubishi Perkins S3Q2 Compact Diesel Engine Block Machining and Cylinder Head Valve Job and Surface

Here’s some pics of a compact diesel engine out of a Caterpillar mini excavator that came in for cleaning, inspecting & machine work. The engine is labeled under the Mitsubishi brand but it is ultimately manufactured by Perkins. It is a three cylinder model S3Q2. The block was machined for cylinder sleeves which were bored [...]

2025-05-21T03:54:42+00:00May 21st, 2025|Machine Shop|

Caterpillar International Navistar Maxxforce Thirteen Diesel Cylinder Head Repairing and Rebuilding

Here’s some pics of an International, or Navistar, Maxxforce 13 diesel engine cylinder head that came in for repairing & rebuilding. The head is off of a piece of Caterpillar equipment. At least two of the cylinders are damaged with burnt & broken valves. There are also numerous cracks in the deck of the head [...]

2025-05-09T00:34:11+00:00May 9th, 2025|Machine Shop|

International Navistar Maxxforce Diesel Cylinder Head Valve Job and Surface Rebuild

Here’s some pics of an International, or Navistar, Maxxforce diesel cylinder head we did a valve job & surface rebuild to. The original head had multiple cracks in most of the cylinders. We ended up exchanging the head with this one. This head has some dings on the surface which are due to some valves [...]

2025-03-28T05:44:18+00:00March 28th, 2025|Machine Shop|

3406 Cat Diesel Cylinder Head Valve Job and Surface Rebuilding Service

Here's some pics of a 3406 Caterpillar cylinder head we rebuilt. The 3406 is one of the most popular diesel engines we've done machine work to over the years. The cylinder head was disassembled, cleaned, magnafluxed for cracks, fully inspected & pressure tested before any machine work was done. After everything checked out okay the [...]

2025-03-26T00:13:58+00:00March 26th, 2025|Machine Shop|

Freightliner Big Cam Cummins Semi Tractor Truck Industrial Two Step Flywheel Surfacing

Here’s some pics of an industrial size two step flywheel we surfaced. We didn't get any pics of it beforehand but someone tried machining it on a lathe which left not only an extremely rough finish but also some deep grooves which we had to grind out. The flywheel bolts to the back of the [...]

2024-11-26T02:14:56+00:00November 26th, 2024|Machine Shop|

Ford V6 Aluminum Cylinder Heads Gasket Surface Machining On CNC Milling Machine

Here’s some pics of a set of 4.0 Ford V6 aluminum cylinder heads we had in for machining. The surfaces of both heads were warped which called for milling the decks, or surfaces, for mating to some new head gaskets. Each head ended up requiring seventeen thousands (.017) of material removal from their surfaces in [...]

2024-11-01T00:14:48+00:00November 1st, 2024|Machine Shop|

John Deere 744E Loader 6101A Diesel Cylinder Head Valve Job and Surface Repair

Here’s some before & after pics of a John Deere diesel cylinder head we reconditioned. The head is off of a 6101A inline six cylinder engine that powers a 744E loader. One of the intake valves as well as one of the exhaust valves were damaged & needed to be replaced. All the other valves [...]

2024-10-30T02:54:09+00:00October 30th, 2024|Machine Shop|

Caterpillar 140M Grader Circle Repairing With Welding and VTL Machining

Here’s some pics of a Caterpillar 140M Grader Circle we have in for repair & reconditioning. The surfaces that the guide shoes & shims interface with are worn & scored. The surfaces are first machined & then welded up. After all the surfaces are built back up after welding the circle is mounted back on [...]

2024-10-25T05:04:33+00:00October 25th, 2024|Machine Shop|

Custom Specialty Machining Of A Threaded Oring Boss Aluminum Hose Connection

Here’s some pics of an aluminum threaded fitting hose connection we fixed on an oil cooler we had in for repair. The threads on the original threaded bung were cross-threaded with a couple of threads stripped out. We machined a new threaded connection out of a piece of solid round aluminum stock. We then cut [...]

2024-09-12T03:14:06+00:00September 12th, 2024|Machine Shop|
