Caterpillar 16M Grader Axle Parts Machining On Rottler EM105H Multipurpose CNC Boring and Milling Machine

Here's some pics of a Caterpillar 16M grader axle & lean arm on our Rottler EM105H Multipurpose CNC boring & milling machine getting machined back to specs. The Axle is getting it's end surfaces milled flat & square with a heavy duty shell mill. The lean arm is getting the bores bored with the RAD [...]

2026-04-21T18:07:19+00:00April 21st, 2026|Machine Shop|

1996 Yamaha YZ125 Two Stroke Cylinder Jug Boring And Honing For Wiseco Forged Piston

Here are some pics of a two stroke cylinder, or jug, for a 1996 Yamaha YZ125 that came in for machining. This cylinder was originally a plated, or Nikasil, jug but it has been previously machined for a conventional press-in sleeve. The bore was scored and needing to be bored & honed to the next [...]

2026-04-08T05:08:37+00:00April 8th, 2026|Machine Shop|

Cast Iron V8 Vortec Chevy and Porsche 944 Aluminum Cylinder Heads Surface Machining Milling and Surfacing

Here are some before & after pics of some cast iron & aluminum cylinder heads we had in for machining. The two cast iron heads are 350 Chevy Vortec heads that both magnafluxed good with no visual cracks. The surfaces were both warped & required milling the decks square & flat. The aluminum head is [...]

2026-03-27T04:47:24+00:00March 27th, 2026|Machine Shop|

Caterpillar 4788991 Moldboard Blade Hanger Bracket Repair With Welding and CNC Machining On Rottler EM105H Multipurpose Boring And Milling Machine

Here are some pics of a blade hanger we reconditioned. The piece is labeled as a bracket by Caterpillar with part number 478-8991. The blade, or moldboard, on an 18M grader hang from this bracket. The rectangular shaped slots house brass wear shims which the blade, or moldboard, slide in. We first machine the three [...]

2026-03-24T23:57:28+00:00March 24th, 2026|Machine Shop|

Speed UTV Manual Alternator Belt Tensioner, Hot Weather Radiator Cooling System Package and Tapp Primary & Secondary Clutches Machining

Here are some pics of some parts we've been machining & working on for the Speed UTV's. We have come up with our own version of a manual alternator belt tensioner. We only have a couple hundred miles on it right now but so far it appears to be holding up well & the belt [...]

2026-03-13T05:17:20+00:00March 13th, 2026|Machine Shop|

1930 Dodge Brothers Old Cast Iron Water Pump Corroded, Pitted and Needs Repairing, Machining and Rebuilding

Here are some before, during & after pics of an old cast iron water pump we rebuilt. The water pump is a 1930 Dodge Brothers. When we got the pump all disassembled we found the housing to be extremely pitted & corroded. The shaft of the pump was also badly pitted & corroded. We machined [...]

2026-02-25T03:02:39+00:00February 25th, 2026|Machine Shop|

Hydraulic Cylinders Worn and Damaged Repairing and Rebuilding

Here are some pics of a couple of hydraulic cylinders we rebuilt. Both cylinders were extensively worn & damaged. The one cylinder had bad scoring in the bore as the shaft was bent. The pistons & seals were also badly worn in both cylinders. New gland nuts, pistons & rod ends were fabricated & [...]

2026-01-30T05:01:36+00:00January 30th, 2026|Machine Shop|

Old Antique Obsolete Hercules Cast Iron Water Pump Machining, Repairing and Rebuilding

Here are some before, during & after pics of an old cast iron Hercules water pump we rebuilt. Antique & obsolete water pumps come in for repair & reconditioning quite often. We completely disassemble the pumps & blast all the parts down to the raw base metal. Most of the time the shafts are [...]

2026-01-30T05:15:55+00:00December 17th, 2025|Machine Shop|

Caterpillar 834H RTD Rubber Tire Wheel Dozer Blade Stabilizer A-Frame Machining and Rebuilding Repair

Here are some pics of a Caterpillar 834H RTD, Rubber Tire or Wheel Dozer, blade stabilizer we reconditioned. The blade stabilizer is often referred to as an A-Frame as well. The two bores on the arms always require boring to get them perfectly round before welding the bores up & then machining them back [...]

2026-01-30T05:19:40+00:00December 3rd, 2025|Machine Shop|

Toyota 4Runner 4WD Offroad V6 5VZFE Engine Machining and Rebuilding

Here’s some pics of a Toyota 4-Runner V6 engine we finished to a shortblock assembly. After cleaning & checking the block, crank & rods for cracks we performed all the machine work. The block got the housing bore align honed, the cylinders bored & honed for new oversize pistons & the decks surfaced & [...]

2026-01-30T05:22:55+00:00November 7th, 2025|Machine Shop|
