Radiator Shop

Here’s some pics of a Caterpillar 793F Mesabi Radiator Module Cooling Package we rebuilt. Rebuilding the Mesabi Radiator itself is a bit of a job. Removing all the external cooling system components for cleaning, repairing & rebuilding is a whole other project. Reinstalling all the external pieces & parts onto the radiator make this a [...]

Here are some progress pics of the Caterpillar 994K Loader Hardnose we're doing a complete overhaul & rebuild to. The twenty five individual aluminum AMOCS radiator cores have been removed, cleaned, repaired & pressure tested before being reinstalled into the hardnose. Once all the radiator cores are installed the system is pressure tested to make [...]

Here are some pics of a Caterpillar 793F Mesabi Radiator Module Cooling Package we picked up for repair and rebuilding. Some of the cooling system components include the two aftercoolers, ac condenser, fan blade, hydraulic fan motor and multiple cooling pipes, hoses & hardware. After we get all the cooling system components removed we will [...]

Here are some pics of a couple different radiator jobs we completed. The two radiators stacked on top of each other on the pallet are for a Caterpillar D10T2 dozer. Both radiators are heavy duty aluminum units. The smaller radiator is for an older Ford LN9000. The original radiator was a copper brass core with [...]

Here are some before, during & after pics of a Caterpillar 793F Radiator Module Cooling Package we overhauled. The radiator itself is a Mesabi. Each individual Mesabi radiator tube was removed for cleaning & reconditioning. All the other cooling system components were cleaned, repaired as needed, pressure tested & painted before final assembly. We rebuild [...]

Here are some pics of a Hitachi EX5600-7 shovel radiator we rebuilt. The radiator is a Mesabi with individual copper fins & tubes. Each tube was removed for cleaning, reconditioning & polishing. All the upper & lower rubber grommet seals were removed & the tanks cleaned & repaired as needed. The bottom tank was leaking [...]

Here are some before & after pics of a Caterpillar 777G water truck radiator we had in for a quick turn-around repair & rebuild service. This radiator is made with Cat's aluminum AMOCS modular radiator cores, or sections. Each core section was cleaned, tested, repaired & re-pressure tested before final assembly of the complete radiator. [...]

Here are some pics of a Caterpillar 793F haul truck radiator cooling package we picked up from one of our mining customers. The radiator itself is a Mesabi which we will do a complete rebuild to. All the individual tubes will be removed for reconditioning and all the rubber grommet seals will be replaced. Behind [...]

Here are some before & after pics of a Cat 793C folded core radiator assembly we rebuilt. The Caterpillar folded core version of the 793C contains sixty individual folded radiator cores. Each section, or core, received a rod & repair with both brass tanks being removed for cleaning, reset & soldered back in place at [...]

Here are some pics of a radiator off of a Hitachi EX5600-7 shovel that we picked up for a repair & return. The radiator is leaking in the corners as well as the gaskets. The side frame has been hit near the center which has the radiator in bind which has lead to the leaks. [...]
