Here are some pics of a Caterpillar 793F Mesabi Radiator Module Cooling Package we rebuilt. This one came to us in pretty rough shape. All the composite fan shroud pieces were cracked & fractured. Several of the threaded bolt holes were stripped out & there were several cracks in the fan guard mounting blocks as [...]
Here are some pics of some tubular exhaust manifolds for a 944 Porsche. Our customer wanted them cleaned inside & out, checked out & ceramic coated. So we thermal cleaned them in our oven & then shotblasted them down to the raw cast iron metal. After they checked out good with no cracks they were [...]
Here are some before & after pics of a Caterpillar Excavator Radiator that came in for rebuilding. The radiator core was internally plugged along with some external damage which was causing the machine to overheat. We recommended recoring the radiator with a new heavy duty high efficiency core. Our customer agreed to recore the radiator [...]
Here are some pics of a Caterpillar 994K loader radiator hardnose cooling system package we rebuilt. This nosecone assembly contains twenty five aluminum AMOCS modular radiator cores, two aftercoolers, two transmission oil coolers, five implement oil coolers, one rear brake cooler and an air conditioning condenser. Each radiator core section & every cooler were all [...]
Here’s some pics of a Caterpillar 793F Mesabi Radiator Module Cooling Package we rebuilt. Rebuilding the Mesabi Radiator itself is a bit of a job. Removing all the external cooling system components for cleaning, repairing & rebuilding is a whole other project. Reinstalling all the external pieces & parts onto the radiator make this a [...]
Here’s some pics of some machining jobs we have in for the engine machine shop department. The two cylinder heads are both Cummins diesel 6.7 liter inline six cylinders. One is off of a 2018 Dodge truck & the other one is a mystery at the moment. They are both getting a valve job and [...]
Here are some progress pics of the Caterpillar 994K Loader Hardnose we're doing a complete overhaul & rebuild to. The twenty five individual aluminum AMOCS radiator cores have been removed, cleaned, repaired & pressure tested before being reinstalled into the hardnose. Once all the radiator cores are installed the system is pressure tested to make [...]
Here are a few pics of a Caterpillar 16M grader circle assembly we're machining the bores on. With our Rottler CNC boring & milling machine we are able to mount large parts & engine blocks for precision line boring as well as many other milling & machining operations. Once the circle assembly is securely mounted [...]
Here are some pics of a Caterpillar 793F Mesabi Radiator Module Cooling Package we picked up for repair and rebuilding. Some of the cooling system components include the two aftercoolers, ac condenser, fan blade, hydraulic fan motor and multiple cooling pipes, hoses & hardware. After we get all the cooling system components removed we will [...]
Here are some pics of a couple different radiator jobs we completed. The two radiators stacked on top of each other on the pallet are for a Caterpillar D10T2 dozer. Both radiators are heavy duty aluminum units. The smaller radiator is for an older Ford LN9000. The original radiator was a copper brass core with [...]
